Field assembly cable connector, Cat.7, shielded, slim type
Brand:LogiLink
Part NoMP0057
EAN:4052792067835
PU:500
- Connector for Cat.6A, Cat.7 and Cat.7A cable
- Suitable for field assembly, no special tools required
- Shielded zinc-alloy metal housing, slim type
- Nickel plated contacts, phoshor bronze
- Wiring code T568A or T568B
- Suitable for 22–24 AWG round cable
- Toolless LSA punch down termination
- Suitable for cables with OD 6 to 8.5 mm
- Wire diameter (insulated): 0.98–1.53 mm
MP0057
MP0057 — LogiLink’s Cat.7 field assembly RJ45 coupler is the perfect solution for a quick and safe assembly of a link either in existing or new networks. LogiLink’s field installable coupler offers a fast and reliable termination without need of special tools or knowledge, it helps to save labor cost and installation time, especially for industrial use.
Applications
Suitable for field assembly, no special tools required. Suitable for 22–24 AWG round cable.
