10"-Rack PDU 4-way German socket, with switch
- Power distribution unit for 10 inch rack mount installation (1 U)
- Robust aluminum housing, IP20
- Sockets: 4x safety socket CEE 7/3, 45° angled
- Connection: German plug (CEE 7/7), angled
- Voltage/Power: AC 230 V, 16 A, 50 Hz, max. 3680 W
- 1.8 m connection cable H05VV-F 3x 1.5mm²
- With on/off switch
- Color: RAL 9005 black
PDU4B01
PDU4B01 — This PDU is specially designed for installation in 10" wall cabinets. The strip consists of a torsion-resistant frame with only one height unit and low profile depth of 44 mm.
The outer shell of the PDU is made of aluminum. The device has a 2m long cable with German safety plug.
Product questions
Responsible entity
Brand: LogiLink
Manufacturer: 2direct GmbH
Registered address: Langenstück 5, 58579 Schalksmühle, Germany
Phone: +49 2351 66887-0
Fax: +49 2351 66887-29
Email: info@2direct.de
Information on safe use:
Use only as intended. Do not connect the power strip to an ungrounded socket. Do not use it with extension cables or adapters that interrupt the grounding connection. The power strip is intended exclusively for use in dry indoor areas. Do not install it near heat-emitting devices such as radiators or heat registers. Do not install it in areas with excessive moisture or other conductive contaminants. Do not expose it to water or start disassembling it. Do not connect devices one after another in a series chain. Do not cover it. Never install electrical wiring during a thunderstorm. The power demand of each device connected to the power strip must not exceed the power strip's output power. The total power demand of all devices connected to the power strip must not exceed its maximum load capacity. It is de-energized only when the plug is removed.
