Cat.6A keystone jack UTP 22-26 AWG, toolless, 16.6 mm width
Brand:LogiLink
Part NoNK4066
EAN:4052792070859
PU:250
- Cat.6A Class EA 10G 500 MHz, 10 Gigabit Ethernet
- Complies with ISO/IEC 11801 and TIA/EIA 568-C
- Toolless, simple connection
- For 22AWG, 24AWG and 26AWG wires
- For round cables with an outer diameter of 5 to 8.5 mm
- Slim design, only 16.6 mm wide
- Supports PoE, PoE+ and PoE++
- 180° cable termination, crocodile type
- Color: black / white
NK4066
NK4066 — RJ45 keystone module for the transmission of digital and analogue signals up to a frequency of 500 MHz. In combination with components of the same or higher quality, this jack is ideal for Cat.6 or Cat.6A cabling with sufficient performance reserves for a Class E or EA link.
This makes it ideal for Gigabit Ethernet or even 10 Gigabit Ethernet (Cat.6A) transmission. Easy installation thanks to tool-free connection.
Applications
For 22AWG, 24AWG and 26AWG wires. For round cables with an outer diameter of 5 to 8.5 mm.
